Exporting .fbx as object sequence (frame by frame).
11991 13 6- PascalBkm
- Member
- 17 posts
- Joined: 5月 2016
- Offline
Hello,
I have an object sequence in sop (every frame generates a new geometry), and I need to export it as frame sequence, something like tree_$F.fbx. But so far the .fbx rop seems to write only the first frame, and some kind of animation data (in a folder called **.fpc).
In other word, I need the frame by frame option from the .abc rop, but for a .fbx format.
Is it any magic workaround to solve this ?
I have an object sequence in sop (every frame generates a new geometry), and I need to export it as frame sequence, something like tree_$F.fbx. But so far the .fbx rop seems to write only the first frame, and some kind of animation data (in a folder called **.fpc).
In other word, I need the frame by frame option from the .abc rop, but for a .fbx format.
Is it any magic workaround to solve this ?
- Vasilis Triantafyllou
- Member
- 32 posts
- Joined: 1月 2015
- Offline
- PascalBkm
- Member
- 17 posts
- Joined: 5月 2016
- Offline
- PAI_SideFX
- Member
- 2 posts
- Joined: 9月 2019
- Offline
PascalBkm
Hello,
A workaround is to create s shelf tool with this :
import hou
node = hou.node(“/path_to_fbx_export_operator”)
for i in range(0,51):
hou.setFrame(i)
node.render()
Hi I saw this post I was trying to do the same thing export fbx sequence frame by frame. But I have no knowledge of using python in Houdini. What is the “path to fbx export operator”? Do you have a video or images of how to set this up so I can use it.
- btangonan
- Member
- 6 posts
- Joined: 4月 2018
- Offline
- vusta
- Member
- 555 posts
- Joined: 2月 2017
- Offline
btangonanopen up your SideFX labs shelf say, rclick on an empty area>New Tool>Script tab
I'm having the same problem. Only the first frame of an animation sequence can be exported as an filmbox FBX.
How does one use the shelf tool?
paste in code above:
import hou node = hou.node(“/path_to_fbx_export_operator”) for i in range(0,51): hou.setFrame(i) node.render()
I've done it here for you WITH indentation, otherwise Python will complain of incorrect indentation
the path should point to your rop_fbx1 (because that has the render on it, otherwise…another error)
something like this: node = hou.node(“/obj/geo1/rop_fbx1”)
maybe change 1st frame to 1 also.
Note: I tested reading it back in….using File node is still incorrect, use Menu: File>Import instead
This sounds stupid, but again make sure in the rop_fbx1 it is outputting range instead of current frame.
Edited by vusta - 2020年6月5日 01:28:13
- keeganmillbern
- Member
- 4 posts
- Joined: 2月 2020
- Offline
vustabtangonanopen up your SideFX labs shelf say, rclick on an empty area>New Tool>Script tab
I'm having the same problem. Only the first frame of an animation sequence can be exported as an filmbox FBX.
How does one use the shelf tool?
paste in code above:import hou node = hou.node(“/path_to_fbx_export_operator”) for i in range(0,51): hou.setFrame(i) node.render()
I've done it here for you WITH indentation, otherwise Python will complain of incorrect indentation
the path should point to your rop_fbx1 (because that has the render on it, otherwise...another error)
something like this: node = hou.node("/obj/geo1/rop_fbx1")
maybe change 1st frame to 1 also.
Note: I tested reading it back in....using File node is still incorrect, use Menu: File>Import instead
This sounds stupid, but again make sure in the rop_fbx1 it is outputting range instead of current frame.
I tried this solution and it exports a single fbx with the animation data inside but not as a series of fbx's ala the example of tree_$F.fbx mentioned in the first post. I have it set to output range and not current frame and Im not totally sure what or if Im doing something wrong
- Jon Meier2
- Member
- 3 posts
- Joined: 5月 2015
- Offline
- Jon Meier2
- Member
- 3 posts
- Joined: 5月 2015
- Offline
- VGriffith
- Member
- 132 posts
- Joined: 9月 2018
- Offline
I cannot for the life of me get this to work. hah! Can anyone bring any new solution to export an FBX sequence as separate files frame by frame?
SyntaxError: ('invalid syntax', ('tool_1', 3, 17, 'node = hou.node(\xe2\x80\x9c/obj/file1/rop_fbx1\xe2\x80\x9d)\n'))
SyntaxError: ('invalid syntax', ('tool_1', 3, 17, 'node = hou.node(\xe2\x80\x9c/obj/file1/rop_fbx1\xe2\x80\x9d)\n'))
Edited by VGriffith - 2021年11月3日 12:37:08
- tamte
- Member
- 8747 posts
- Joined: 7月 2007
- Offline
- TheReyplay
- Member
- 6 posts
- Joined: 8月 2019
- Offline
- teeoemm
- Member
- 3 posts
- Joined: 6月 2021
- Offline
keeganmillbernvustabtangonan
...import hou node = hou.node(“/path_to_fbx_export_operator”) for i in range(0,51): hou.setFrame(i) node.render()
I've done it here for you WITH indentation, otherwise Python will complain of incorrect indentation
...
Following up on this since I just got it to work.
2 things I had to do:
- Use single (ie. '/obj/geo1/rop_fbx1') quotes around the path name. Copy and paste inputs special start/end quote characters which cause a syntax error.
- Set the rop_fbx 'Valid Frame Range' to 'Render Current Frame'. I don't understand why, but it works.
Also, make sure you set
range(0,51)
to your correct frame range if you're missing models.Bonus tip since I had some trouble with this:
I can't use $F in the output name since I wanted to preserve the original filenames from the models I'm importing.
To set a custom name attribute for your files you can create a detail attribute and use this format --> $HIP/prefix_`details("../SOME_NULL", "filename")`.fbx
in the output file field.
Bold characters will need to be changed to match your setup. This didn't work using "." , so SOME_NULL is a Null node I created just before the rop_fbx, and after creating the detail attrib called "filename".
The prefix_ is not necessary, obviously, but be careful you don't overwrite the original models.
- edschiffer
- Member
- 13 posts
- Joined: 9月 2016
- Offline
So, one dirty easy way you can do this is simply use the File SOP set to write *_$F.fbx and play your frame range.
It's missing all the FBX options but it did do the job for me, as I need to import it as "geometry cache" in an old software.
I just wish the ROP FBX Output frame range would work, and I also couldn't make TOPs export this quickly. This dirty method above is much much quicker for my case.
It's missing all the FBX options but it did do the job for me, as I need to import it as "geometry cache" in an old software.
I just wish the ROP FBX Output frame range would work, and I also couldn't make TOPs export this quickly. This dirty method above is much much quicker for my case.
-
